BS 641 table 2.
Pan Head Solid Rivet
Pan Head Solid Rivet
Standard Proportions:
A= 1.6 D
B= 0.7 D
B= 0.7 D
|
|
|
|
|
|||
|
D
|
A
|
B
|
||||
|
Inch
|
mm
|
Inch
|
mm
|
Inch
|
mm
|
|
|
3/16
|
0.188
|
4.76
|
0.300
|
7.61
|
0.131
|
3.32
|
|
1/4
|
0.250
|
6.35
|
0.400
|
10.16
|
0.175
|
4.44
|
|
5/16
|
0.313
|
7.94
|
0.500
|
12.70
|
0.219
|
5.56
|
|
3/8
|
0.375
|
9.53
|
0.600
|
15.24
|
0.263
|
6.68
|
|
7/16
|
0.438
|
11.11
|
0.700
|
17.77
|
0.306
|
7.77
|
Materials available:
Most materials including Steel, Brass, Copper, Aluminium,
Aluminium Alloy and Stainless Steel (430 & 394 type).
